Round-Trip Parity on a Code-First Design System

Astryx is Meta’s largest design system, open-sourced in June 2026: 149 components, and no official Figma kit. That is a deliberate position, not an oversight — the system is code-first, the repository is the source of truth, and there is no designer-facing token sync. It also means a designer has nowhere to draw. A screen either starts in code, or it starts in a design file nobody can prove matches the system.

The reflex is to rebuild the library by hand: 149 components, redrawn, stale by the next release. The bridge belongs at the token layer, not the component layer. Tokens are a small, enumerable set, and they are what actually decides whether a screen looks like the system.

The second choice was the design tool. Pencil.dev, because a .pen file lives in the repository next to the code — one agent, one loop, no handoff between two applications that cannot see each other.

A code-first system without a design surface does not fail loudly. It fails by routing every visual decision through whoever can read the repository, and by making fidelity a matter of opinion. Left alone, the split produces four things:

None of these are visible in a design review. They are measurement gaps — the design and the code look close enough, and nobody can say by how much.

A component-level bridge asks: can I redraw the library? A token-level bridge asks a smaller and far more durable question: does this design paint values the system actually defines?

That turns a design file into something testable. The token set is finite, the running app resolves it, and the .pen file is text in the same repository — so one agent can read both sides of the loop, and a gate can score it on every change.

This is the part that reshaped the work, and the part worth stealing. Four separate times, a measurement that looked correct was measuring the wrong thing.

The third one is the dangerous one. A failing check gets investigated; a passing check that measures the wrong object gets trusted — the gate was green, and it was answering a different question than the one being asked of it.

So the harness grew a second lens — one that scores the values a single page actually paints — and later a third for the design file itself. A deliberately broken page now ships with them as a permanent fixture. Both pages below score the same on the first lens. Only one of them is the real screen.

With a trustworthy instrument, the question becomes worth asking: what does a skill actually buy? The same design, the same prompt, the same model and effort, a fresh context in both runs. The only difference was that the second agent was told to read and apply the skill.

The numbers were read back from the gate, not from the agents’ own reports — and with an assertion that the instrument itself was untouched, because the skilled run edited the token map mid-run and reverted it. A subagent’s report is not evidence.

The whole delta is carried by one nameable thing: geometry outside the scale. The design file itself carries cornerRadius 999 on 40 nodes, and the unskilled run copied it faithfully into 160 nodes of code — the system’s --radius-full is 9999px, one digit apart — plus 2px on 52 more and 8px on 8. The skilled run emitted none of them: it read the real radius scale off the running app and snapped the off-scale values to it. The drift was inherited, not invented, which is the more uncomfortable finding — a design file is what the next screen gets built from.

The same experiment then ran the other way — mirroring a live screen back into the design file, with the skill again as the only variable. Both tables below are read off the same harness. The 100% in the second one is not a saturated gate: the same run binds only 92% of its values to tokens, which is exactly why each lens reports more than one number.

A case study that only reports wins is not a measurement. Four things are worth naming, and each of them makes the rest more credible, not less.

• The baseline was hard, not straw.

  The repository auto-injects Astryx’s own agent documentation, which already says “tokens for every value, no raw hex or px.” Taking the docs away from the unskilled agent was not physically possible, and would have been dishonest. That is why the baseline starts at 82%, not 20% — the delta is smaller and it survives “any model would do that.”

• Two colors survived both runs.

  #0B991F and #8494A3 are literals inside the .pen file, not token references, and the running app resolves nothing matching them — no --color-data-* family exists. Both agents in the first pair reproduced them faithfully, so they do not separate those two runs. The reverse-direction run under the skill later replaced them with declared tokens, which is where that rule stopped being a hypothesis.

• The ceiling is not 100%.

  The charting library paints its own defaults — 11px spacing, #0074e2 — and they score as off-system because that is exactly what they are.

• The write path is evidence, not proof.

  The .pen format turned out to be canonical JSON — parse and re-serialize reproduces a 190KB file byte for byte — so writing it needs no vendor tool, and a validator rejects duplicate ids, undeclared tokens and dangling references. What was never confirmed is that the design application opens a file written that way.

Both directions are measured here, on the same harness. What is not measured is a from-scratch draw with no existing frame to copy from — that pair is still to run.

The transferable part is not Astryx, and it is not Pencil. It is that “does this design match the system?” can be a number instead of an opinion — and that the number is worth exactly what its instrument is worth.

Written as a practice

• Bridge at the smallest shared layer

  tokens are enumerable and cheap to keep in sync; component libraries are neither

• Measure against the running product

  built packages, design files and documentation each answer the token question wrong, in a different way

• Make the gate fail on purpose

  a check that has never failed is a check nobody has tested

• Report what did not move

  the findings a measurement refuses to confirm are what make the confirmed ones worth reading

• Carry the one fact an agent cannot look up

  the delta came from a single sentence about which layer wins, not from tone, length or encouragement

• State the rule as a decision, not a list

  “a value that exists nowhere on the scale is a finding, not a requirement” catches 999px; an enumerated list of allowed radii never would

A design system that lives in code is not a system designers are locked out of. It is a system where the question of fidelity finally has an answer you can run, on every change, instead of arguing about it in review.
